Chipset: Intel C602
CPU Pin: Supports Intel LGA2011 platform processors
Memory Slots: 4 DDR3 memory slots
Memory Standard: Supports quad-channel DDR3 1866/1600/1333/1066MHz memory (depending on CPU), maximum support 128GB
Storage Interfaces: 2 SATA 3.0 6Gbps hard drive interfaces, 4 SATA 2.0 3Gbps hard drive interfaces
Expansion Slots: 2 PCI Express 3.0 x16 slots, 1 PCI Express 3.0 x4 slot, 1 PCI Express 2.0 x1 slot
Expansion Interfaces: 1 M.2 2280 NVMe PCIe x4 3.0, 1 M.2 2280 NVMe PCIe x4 2.0, 1 M.2 NGFF WIFI
Onboard Audio Card: Realtek High Faith Audio ALC897
Onboard Network Card: Gigabit Ethernet RTL8111K
Power Interface: 24PIN + 8PIN
Fan Sponsors: 1 CPU_FAN header, 2 SYS_FAN headers
Power Phases: 7-phase
PCB Layers: 8 layers
Motherboard Size: 305*220MM ATX form factor
Rear Panel I/O: 1 PS/2 keyboard/mouse port, 2 USB 3.0 ports, 6 USB 2.0 ports, 1 RJ Ethernet port, 1 5-pin audio jack, 1 optical audio jack
Front Panel I/O: 2 USB 2.0 headers, 1 USB 3.0 header, 1 front audio header, 1 COM header, 1 1-pin TPM 2.0 header, 1 POST/POST header, 1 POST/POST button
